The senders are pre-wired from the factory. Your Trailer-Up Switch will raise the drive OK but the TRIM Switch does not work.
I replaced the gauge thinking it might be bad but no.
Alpha one trim gauge power no change. Lower the drive all the way and adjust the sending unit to make the trim gauge read full down. If the gauge still does not read then check to make sure that the wiring is good. There should be 4 wires to the gauge 12V purple ground black gauge.
Your Trailer-Up Switch will raise the drive OK but the TRIM Switch does not work. Your Trim gauge does not work. Trim Sender Units The trim senders are no longer sold individually.
The Port switch is the Trim Limit Switch. This limits how far up the drive will trim. The Starboard switch is the Trim Level Sender switch.
This sends a signal to the trim gauge. If one or the other malfunctions you will need to get the entire Kit. The Kits comes with both senders.
The senders are pre-wired from the factory. I have an 89 mercruiser alpha one 30. My trim works just fine and there is power going to the guage.
However the gauge doesnt work. I replaced the gauge thinking it might be bad but no. When this switch fails the TRIM BUTTON does not work.
Only the TRAILER BUTTON will work. When one switch fails you will end up replacing both switches. This is because the switches are sold in sets of two.
Both the Trim Limit and the Trim Sender switches are sold together as a pair. The trim limit switch limits the amount of upward movement so you dont over trim. Experience will tell you the best running angle so in time you wont even need it.
The trim position sender only tell you where the trim position is which is soon unnecessary with a little experience. Its pretty much a waste of money in my book. One wire is grounded near there and the other is connected to a terminal.
If you dont get a voltage reading at the terminal junction apply 12 VDC to see if the trim gauge moves. If it does check for voltage back at the trim pump connections. If no voltage there apply 12 VDC there to check gauge movement.
Trim Limit Switch Adjustment. June 2016 in General Boating Discussions. Not the sender- that was not tricky at all but the limit switch.
Alpha one gen two. How do you do it. Ive read it is done by measurement of the rams and after raising it from fully down- but.
Yeah that didnt work. I have a good ground and 105 volts at the power wire going to gauge. 105V at the power wire is no bueno.
If your batteries have been sitting at that voltage for long they could be toast. Do not attempt to adjust the trim sender on the port side of the gimbal ring as that is your trim limit switch and has no relation to the trim gauge function. Just bought 2013 four winns h190 with merc 43L Alpha.
Power trim was fine but just stopped raising past mid level but operates in down range. Power trim gauge needle rests at bottom of green WC. Recheck instrument reading and turn ignition key OFF.
Trim Indicator Gauge Testing 1. Check gauge terminals and connections for looseness or corrosion. Disconnect leads at gauge terminals.
Connect a jumper lead between the red wire. Alpha One Trim Wiring Diagram Mercruiser Power Solenoid Troubleshooting Drive Trims But Not Up Marine 35 Sender. On the Mercury Bravo Drive the sensor does not even have 90 angle.
You can turn the sender around all 360 but the actual angle. For measuring is far smaller. I cannot look right now and the.
Installation we did was 12a year ago. 270 seems a bit exaggerated for a trim sensor. Trim Position Sender Installation.
Install trim position sender as follows. Place sterndrive unit in the full DOWNIN position. Turn center rotor of trim.
The trim gauge is simply the last one on that side so the daisy chain comes to an end. Trim sender and clean off some of the grease then retest. The most common elements are capacitor resistor and battery.
Additionally there are other elements like floor switch motor and inductor. It all depends on circuit thats being assembled. According to earlier the traces at a Mercruiser Trim Sender Wiring Diagram signifies wires.
Sometimes the wires will cross. The boat is a 30 year old 21 Eliminator Sport with a Gen 1 Alpha. The drive has been apart and some parts have been replaced.
I am the 2nd owner but to my knowledge it has never been in salt water. I dont really need the trim switch and guages to work but I would rather everything work as it is supposed to. Disconnect trim limit switch wires at the power trim pump.
Also disconnect trim sender wires at the engine harness. Route new trim limit switch wires through hole. Bring together the two grommet halves and ensure they are seated tightly in the hole and that the flat edges that mate together are vertically aligned.
The cure is to loosen one of the large tiltsteering nuts 12 turn then with a 24 and a large hammer force the swivel bracket sideways slightly. Force grease into the grease fittings on the front of the swivel bracket. That should do it.
POWER TILT TRIM Temporary Down Lockup. Trim Sender Kit for most Mercruiser sterndrives. It is located on both sides of the Gimbal Ring and will fit most MRAlpha One Alpha One Gen II and Bravo drives.
One of these switches is the sender for the guage and the other is a limit switch to keep you from over trimming the drive and having cavitation. They are not sold separately. 90-806534970 1096 Alpha One Generation II Sterndrive 2 - 11 Drive Shaft Housing Shimming Gear Distance Driven Gear SHIMMING TOOL 91-60526 Overall Drive Unit Gear Ratio Tool Position 1471 1621 1811 1941 2401 Z X Y Y Y 23012 a025 064mm a - Feeler Gauge - 025 in.
0635mm Gear Distance Drive Gear 23012025 064mm a 23012 SHIMMING TOOL 91-60523. This chapter covers three MerCruiser power trim and tilt systems. The or handle a pump motor and a trim limit switch from the trim control harness inside the boat see.
Figure 1 or Reconnect wires to back of new switchsender. Disconnect the trim limit switch and connect the 2 wires with the blue and purple Diagram of Alpha One Gen II Drive. Power Tilt And Trim Wiring Wiring Diagram Schematic Name Mercruiser Trim Sender Wiring Diagram.
